Features
CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AACYes / Yes / No / Yes / Yes / No
CD-Text / SA-CD Text / ID3 Tag / WMA Meta Tag / AAC Meta dataNo / No / Yes / Yes / Yes
Data Disc Compatibility: DSD / WAV / ALACNo / No / No
DAC operation mode: USB / Coax / OpticalNo / No / No
Asynchronous mode rear USBNo
Bit-perfect transmissionNo
USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6No
Signal isolator for DAC Mode operationNo
HDAM versionHDAM+HDAM SA2
Power Transformer: Toroidal / ElNo / Yes
High Grade Audio ComponentsYes
Customised ComponentsYes
Symmetric circuit layoutYes
Copper Plated ChassisNo
Extra metal plate for chassis strengthingYes
Digital out off / Audio EX ModeYes / No
Headphone: Standard / Buffer / Current feedbackNo / Yes (HDAM-SA2) / No
Others
Selectable filter: CD / SA-CD / DAC-ModeYes / No / No
Marantz Musical MasteringYes
Marantz Musical Mastering StreamNo
Marantz Musical Mastering ConversionNo
Separated rectifier circuit for analogue and digital circuitryYes
Display: Dimmer / OffYes / Yes
Low noise LCD displayNo
5mm Aluminum top coverNo
Playback
Program Play (CD / SA-CD)25
RepeatYes
Random PlayYes
Start Sound Mode for SA-CDNo
Inputs Outputs
Analogue Out (Cinch)2ch
Balanced OutNo
Digital Optical In / OutNo / 1
Digital Coaxial In / OutNo / 1
Sample Rate digital InNo
Gold Plated CinchYes
USB Audio (Front) / Made for iPod / Made for iPhone®Yes / No / No
USB-A: FLAC / WAV / AIFF / ALAC / DSDYes
USB type B input for PC (rear)No
Asynchronous mode rear USBNo
Sample Rate USB type B InNo
USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6No
D-BusYes
Headphone OutYes
Headphone Volume ControlYes
Specifications
MechanismNo
D/A ConversionNo
Low Pass Filter stageNo
Output BufferNo
Headphone ampNo
Frequency Response (Cust.)No
Dynamic Range (SA)No
Signal to Noise Ratio (SA)No
Total Harmonic Distortion (SA)No
Channel Separation (SA)No
Frequency Response2 Hz - 20 kHz
Dynamic Range100 dB
Signal to Noise Ratio110 dB
Total Harmonic Distortion0.002%
Channel separation98 dB
General
Available Colors: Gold / Silver / Black / Silver-GoldNo / No / Yes / Yes
Metal Front PanelYes
Remote ControlRC004PMCD
Power Consumption in W32
Standby Consumption in W0.3
Auto Power offYes
Detachable Power CableYes
Maximum Dimensions (W x D x H) in inches17.3 x 13.3 x 4.1
Weight in lbs.14.3
Carton Maximum Dimensions (W x D x H) in inches20.3 x 18.4 x 7.4
Carton Weight (inc. product) in lbsNo Value
