Boulder
£28,000

1110

What is it that makes the 1110 preamplifier so special? It is something rare, an overachiever, a unique combination of reference-level performance and compact, convenient design.

1110

Preamplifier

What is it that makes the 1110 preamplifier so special? It is something rare, an overachiever, a unique combination of reference-level performance and compact, convenient design. It is at once familiar in size and shape and yet completely new in aesthetic design detail. Perhaps what makes it so special is that it takes such amazing sight, sound, use, and feel and packs them all into a single chassis. It is the perfect mix of traditional function and cutting-edge technology, earning more than 10 international product awards from media around the world.

It is, after all, a Boulder, and every Boulder is special.

Features

  • Five pairs of programmable, differentially-balanced inputs
  • Large, easy-to-read, LCD display
  • Full surface-mount circuit board architecture manufactured on Boulder's own precision pick-and-place machine
  • Boulder's own 983 gain stage means excellent buffering and current drive for long cable runs
  • Balanced version of Boulder's own analog volume control, descended from the 3010 Preamplifier, for superior clarity and noise elimination
  • Available IP control connection for simple use connection to home automation systems
  • Comprehensive setup and options programming for all inputs and preamplifier functions
  • Embedded ARM processor controls all preamplifier functions and setup options
  • Each input can be configured for Theater Mode when integrated into home cinema systems
  • Unique front panel design displays the topographical map of Flagstaff Mountain, located near Boulder, Colorado
  • Automated online software management for worry-free updating
  • Dual-mono audio boards isolate left and right channels for perfect stereo separation in a single-chassis design

Specifications

Input Connections5 pairs balanced line level
Output Connections2 pairs balanced main, 1 pair balanced auxiliary
Volume100 dB range in 0.5 dB steps (200 steps) or 1.0 dB steps (100 steps)
Maximum Input Level6.0 Vrms
Maximum Output Level14.0 Vrms
THD+N, 2V Output, 20 Hz - 20 kHz0.0015% (-96.5 dB)
Output Loaded with 150 ohmsLess than 1 dB distortion change, 20 - 10 kHz
Maximum Voltage Gain20 dB
Auxiliary Path Gain, Balanced Output8.5 dB balanced 2.5 dB unbalanced
Frequency Response, 20 Hz - 20 kHz+0.00, -0.03 dB
Frequency Response, -3 dB at0.02 Hz and 250 kHz
Clip to Noise Ratio118 dB
Crosstalk, L to R or R to L-101 dB or better, 20 Hz to 20 kHz
Crosstalk, Adjacent Inputs-115 dB or better, 20 Hz to 20 kH
Input Impedance100k ohms, balanced 50k ohms, unbalanced
Output Impedance100 ohms, balanced 50 ohms, unbalanced
Control SystemIP (Ethernet), IR, Boulder Net
Weight36 lbs. (16.3 kg), Shipping: 49 lbs. (22.2 kg)
Power Requirements100, 120, 220-240 VAC, 50-60 Hz
Power Consumption75W maximum
